Metecno Lanka offers an extensive range of high performance Mineral wool (Rock wool) sandwich panels for roof and wall system, which are fire proof and sound proof solution for many building applications. Mineral Wool (Rock wool) are non-combustible with a melting point more than 1800 degree Celsius. They are particularly suitable for fire protection, sound reduction and thermal insulation. We also offer enormous aesthetics flexibility with the vast range of colors. Together with advanced inter lapping, fixing mechanism and with range of accessories enables Metecno Lanka to deliver complete building solution. Metecno Lanka can also make custom length mineral wool to suit your exact design and help to optimize structural efficiency. Metecno Mineral wool sandwich is a 5 in 1 solution comprising of,
Roof / Cladding
Ceiling
Fire Proof
Sound Proof
Heat Insulation
Roof / Cladding
Ceiling
Fire Proof
Sound Proof
Heat Insulation
Mineral Wool roofing and cladding panels have five integrated features in one product. It has the roof (or the wall) and the ceiling which will be installed at once. It will also provide excellent heat insulation and it is a fully fire and sound proof product.
Hipertec Roof
The HIPERTEC ROOF panel, manufactured in accordance with a system patented by Metecno, consists of a profiled external steel sheet & an internal ribbed steel sheet, with an insulation core of orientated fiber high density Rockwool, arranged perpendicularly with off-set joints and transversely compacted, in such a way to fill the space between the metal facing. The panel uses steel sheets coated both sides with AZ 150 Zinc Alluminium Alloy for superior durability. Self-supporting insulation panel insulated with Mineral wool (Rock wool) for roof appllications, which require a high degree of fire resistance, sound insulation & thermal insulation.
The HIPERTEC ROOF Panel fulfills all requirements for “non- combustible construction material”. For the thickness 100mm and over the fire resistance is more than 120 minutes.Building material class A1-S1-D0, incombustible in accordance with DIN EN 13501-1, core material A1, incombustible, Melting point > 1000 C.
The HIPERTEC ROOF SOUND panel is particularly suitable for acoustic control, providing excellent sound absorption qualities over a wide range frequency spectrum. Its perforated internal liner sheet enables to improve both sound insulation and sound absorption where the panel is implemented. The Hipertec Roof Sound panel can reduce sound level more than 30 dB and its depends on the frequency. The sound insulation behavior of the Panel at various frequencies are shown in the graph.
Specifications
| S | K | Panel Weight | Sheet Thickness | |
| mm | Kcal/m2h 0C | Watt/m2 0C | kg/m2 | mm |
| 50 | 0.65 | 0.75 | 13.75 | 0.47/0.60 |
| 75 | 0.39 | 0.51 | 16.25 | 0.47/0.60 |
| 100 | 0.34 | 0.40 | 18.75 | 0.47/0.60 |
| 150 | 0.23 | 0.27 | 23.75 | 0.47/0.60 |
Hipertec WALL
The HIPERTEC WALL panel, manufactured in accordance with a system patented by Metecno, consists of a profiled external steel sheet & an internal ribbed steel sheet, with an insulation core of orientated fiber high density Rockwool, arranged perpendicularly with off-set joints and transversely compacted, in such a way to fill the space between the metal facing. The panel uses steel sheets coated both sides with AZ 150 Zinc Alluminium Alloy for superior durability. Self-supporting insulation panel insulated with Mineral wool (Rock wool) for roof appllications, which require a high degree of fire resistance, sound insulation & thermal insulation.
The HIPERTEC WALL Panel full fills all requirements for “non- combustible construction material”. For the thickness 100mm and over the fire resistance is more than 120 minutes.Building material class A1-S1-D0, incombustible in accordance with DIN EN 13501-1, core material A1, incombustible, Melting point > 1000 C.
The HIPERTEC WALL SOUND panel is particularly suitable for acoustic control, providing excellent sound absorption qualities over a wide range frequency spectrum. Its perforated internal liner sheet enables to improve both sound insulation and sound absorption where the panel is implemented. The Hipertec Roof Sound panel can reduce sound level more than 30 dB and its depends on the frequency. The sound insulation behavior of the Panel at various frequencies are shown in the graph.
Specifications
| S | K | Panel Weight | Sheet Thickness | |
| mm | Kcal/m2h 0C | Watt/m2 0C | kg/m2 | mm |
| 50 | 0.65 | 0.75 | 14.15 | 0.47/0.60 |
| 75 | 0.39 | 0.51 | 16.65 | 0.47/0.60 |
| 100 | 0.34 | 0.40 | 19.15 | 0.47/0.60 |
| 150 | 0.23 | 0.27 | 24.15 | 0.47/0.60 |
Hipertec SUPERWALL
The HIPERTEC SUPERWALL panel, manufactured in accordance with a system patented by Metecno, consists of a profiled external steel sheet & an internal ribbed steel sheet, with an insulation core of orientated fiber high density Rockwool, arranged perpendicularly with off-set joints and transversely compacted, in such a way to fill the space between the metal facing. The panel uses steel sheets coated both sides with AZ 150 Zinc Alluminium Alloy for superior durability. Self-supporting fire-resistance insulation panel system, insulated with Mineral wool (Rockwool), with a concealed-fixing method for high quality industrial and commercial buildings, where good aesthetics are paramount..
The HIPERTEC SUPERWALL Panel full fills all requirements for “non- combustible construction material”. For the thickness 100mm and over the fire resistance is more than 120 minutes.Building material class A1-S1-D0, incombustible in accordance with DIN EN 13501-1, core material A1, incombustible, Melting point > 1000 C.
The HIPERTEC SUPERWALL SOUND panel is particularly suitable for acoustic control, providing excellent sound absorption qualities over a wide range frequency spectrum. Its perforated internal liner sheet enables to improve both sound insulation and sound absorption where the panel is implemented. The Hipertec Roof Sound panel can reduce sound level more than 30 dB and its depends on the frequency. The sound insulation behavior of the Panel at various frequencies are shown in the graph.
Specifications
| S | K | Panel Weight | Sheet Thickness | |
| mm | Kcal/m2h 0C | Watt/m2 0C | kg/m2 | mm |
| 50 | 0.65 | 0.75 | 14.55 | 0.60/0.60 |
| 75 | 0.39 | 0.51 | 17.05 | 0.60/0.60 |
| 100 | 0.34 | 0.40 | 19.55 | 0.60/0.60 |
| 150 | 0.23 | 0.27 | 24.55 | 0.60/0.60 |
